$37.89
Original: $126.29
-70%5in1 Dimming Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM LED Driver, 24V 96W—
$126.29
$37.89The Story
| Model | VBD-024-096C2DM5i1 |
| Input Voltage | 100-277V AC |
| Input Current | 1.3A |
| Frequency | 50-60 Hz |
| Power Factor | >0.95 |
| Output Voltage | 24V DC |
| Output regulated Current | 4A |
| Output Power | 96W max |
| Dimmable | Yes (Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM) |
| IP Rating | IP67 (Dry, Damp and Wet Locations) |
| Dimensions | 221mm x 94.34mm x 40.80mm (8.7in x 3.75in x 1.6 in) |
| Class Certification | Class 2 |
| Certifications: |    |
| Applicable for dry, damp, and wet locations |
|
Compatible with Forward-Phase, Magnetic low Voltage & Triac dimmers |
Features:
- 5-in-1 dimming LED driver supporting Triac, Phase, MLV, ELV, 0-10V, Potentiometer, and 10V PWM dimming methods
- Input voltage range: 100-277V AC, input current: 1.3A, frequency range: 50-60 Hz
- High power factor (>0.95) for efficient power utilization
- Output voltage: 24V DC, regulated current: 4A
- Maximum output power: 96W
- Class 2 certified for safe operation in low voltage applications
- IP67 rating for use in dry, damp, and wet locations
- Compact dimensions: 221mm x 94.34mm x 40.80mm (8.7in x 3.75in x 1.6 in)
- UL and FCC certified for electrical safety and compliance with electromagnetic interference standards.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
| Model | VBD-024-096C2DM5i1 |
| Input Voltage | 100-277V AC |
| Input Current | 1.3A |
| Frequency | 50-60 Hz |
| Power Factor | >0.95 |
| Output Voltage | 24V DC |
| Output regulated Current | 4A |
| Output Power | 96W max |
| Dimmable | Yes (Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM) |
| IP Rating | IP67 (Dry, Damp and Wet Locations) |
| Dimensions | 221mm x 94.34mm x 40.80mm (8.7in x 3.75in x 1.6 in) |
| Class Certification | Class 2 |
| Certifications: | |
| Applicable for dry, damp, and wet locations |
|
Compatible with Forward-Phase, Magnetic low Voltage & Triac dimmers |
Features:
- 5-in-1 dimming LED driver supporting Triac, Phase, MLV, ELV, 0-10V, Potentiometer, and 10V PWM dimming methods
- Input voltage range: 100-277V AC, input current: 1.3A, frequency range: 50-60 Hz
- High power factor (>0.95) for efficient power utilization
- Output voltage: 24V DC, regulated current: 4A
- Maximum output power: 96W
- Class 2 certified for safe operation in low voltage applications
- IP67 rating for use in dry, damp, and wet locations
- Compact dimensions: 221mm x 94.34mm x 40.80mm (8.7in x 3.75in x 1.6 in)
- UL and FCC certified for electrical safety and compliance with electromagnetic interference standards.
